TRAG / S

TRAG / S

CRUSHER

Standard Equipment

Carbon steel chassis.
Wear-resistant feeder teeth.
60x12 blade rotor with M-20 screw.
Rear fixed wheels.
Crushing with rear screen.
Freewheel unit with 1" 3/4 Z6 input shaft.
Type G9 transmission.
Double-row oscillating roller bearings.
Hydraulic feeder with flow regulator.
Skid plates.
1" double chain.
400 cm3 hydraulic motor. Chain tensioner with jam relief.
Folding rear screen for maintenance.
Belt tensioner.

Options

Blades.
Code: 008224/013449

Mounted with rear roller.
S/C

MODELS

Code
011392

Working Width (mm)
1300

Dimensions
1648x1390x1202

Number of Blades
40

Rotor (mm) A
510

Rotor (mm) B
195

PTO
540

Power. Min/Max(CV)
60-100

No. Straps / Type
5XPB

Weight (Kg)
1050
Code
013308

Working Width (mm)
1500

Dimensions
1848x1390x1202

Number of Blades
48

Rotor (mm) A
510

Rotor (mm) B
195

PTO
540

Power. Min/Max(CV)
70-100

No. Straps / Type
5XPB

Weight (Kg)
1100
Code
007665

Working Width (mm)
1800

Dimensions
2148x1390x1202

Number of Blades
84

Rotor (mm) A
510

Rotor (mm) B
195

PTO
540/1000

Power. Min/Max(CV)
80-120

No. Straps / Type
6XPB

Weight (Kg)
1350
Code
009095

Working Width (mm)
2100

Dimensions
2448x1390x1202

Number of Blades
84

Rotor (mm) A
510

Rotor (mm) B
195

PTO
540/1000

Power. Min/Max(CV)
90-120

No. Straps / Type
6XPB

Weight (Kg)
1450
